gdx-TinyVG

A libgdx parser and renderer for TinyVG https://www.tinyvg.tech/

What is TinyVG?

SVG is a horribly complex format and an overkill for most projects. The specification includes way too many edge cases so implementing a new SVG renderer will always have drawbacks or missing pieces.

TinyVG tries to be simpler. Fewer features, but powerful enough to cover 90% of use cases. ~ https://tinyvg.tech

Convert SVG into TVG

Make sure to set the following export settings:

• "inline style" (and not for example "internal css")
• Convert text to path

Then simply convert your SVG into a TVG here: https://svg-to-tvg-server.fly.dev/

Only linear and radial gradients with two points are supported. Everything else should convert decently enough.

Video

Here's a youtube video showcasing the library:

Example

public class Lwjgl3Launcher {
  public static void main(String[] args) {
    createApplication();
  }

  private static Lwjgl3Application createApplication() {
    return new Lwjgl3Application(new Main(), getDefaultConfiguration());
  }

  private static Lwjgl3ApplicationConfiguration getDefaultConfiguration() {
    Lwjgl3ApplicationConfiguration configuration = new Lwjgl3ApplicationConfiguration();
    // By default, stencils are disabled, we need those though. So let's enable them here (It's the 6th value. Change that to >= 2).
    configuration.setBackBufferConfig(8, 8, 8, 8, 16, 2, 0);
    // ...

    // In a legacy desktop project it's:
    config.stencils = 2; // >= 2
    return configuration;
  }
}

public class Example extends ApplicationAdapter {
  private TinyVG tvg;
  private TinyVGShapeDrawer drawer;
  private Viewport viewport = new XXXViewport(xxx, xxx);

  public void create() {
    var assetLoader = new TinyVGAssetLoader();
    tvg = assetLoader.load("file.tvg"); // only works with the binary file format

    // TinyVGShapeDrawer requires a 1x1 white pixel file,
    // so either create one in your favourite art program or
    // use the other constructor which creates one for you.
    // https://github.com/lyze237/gdx-TinyVG/blob/main/src/test/resources/pixel.png
    drawer = new TinyVGShapeDrawer(new SpriteBatch(), new TextureRegion(new Texture("pixel.png")));
    drawer = new TinyVGShapeDrawer(new SpriteBatch());

    // You're also able to create a texture region directly out of a tvg file:
    var tvgRegion = TinyVGIO.toTextureRegion(tvg, drawer);
  }

  public void render() {
    Gdx.gl.glClearColor(0.25f, 0.25f, 0.25f, 1);
    Gdx.gl.glClear(GL20.GL_COLOR_BUFFER_BIT);

    viewport.apply();

    drawer.getBatch().setProjectionMatrix(viewport.getCamera().combined);

    // Centers origin and rotates it.
    tvg.centerOrigin();
    tvg.setRotation(tvg.getRotation() + 10 * Gdx.graphics.getDeltaTime());

    drawer.getBatch().begin();
    tvg.draw(drawer);
    drawer.getBatch().end();
  }

  @Override
  public void resize(int width, int height) {
    viewport.update(width, height, true);
  }
}

Alternatively you can load it via an AssetManager

public class Example extends ApplicationAdapter {
  private TinyVG tvg;
  private TinyVGShapeDrawer drawer;
  private Viewport viewport = new XXXViewport(xxx, xxx);

  public void create() {
    var assetManager = new AssetManager();
    assetManager.setLoader(TinyVG.class, new TinyVGAssetLoader());

    assetManager.load("square.tvg", TinyVG.class);

    assetManager.finishLoading();

    var tvg = assetManager.get("square.tvg", TinyVG.class);
  }
}

Or directly create a texture region out of it:

public class Example extends ApplicationAdapter {
  public void create() {
    var drawer = new TinyVGShapeDrawer(new SpriteBatch(), new TextureRegion(new Texture("pixel.png")));

    var assMan = new AssetManager();
    assMan.setLoader(TinyVG.class, new TinyVGAssetLoader());
    assMan.setLoader(TinyVGTextureAssetLoader.Result.class, new TinyVGTextureAssetLoader());

    assMan.load(file, TinyVGTextureAssetLoader.Result.class, new TinyVGTextureAssetLoader.Parameters(drawer));

    assMan.finishLoading();

    tvg = assMan.get(file, TinyVGTextureAssetLoader.Result.class).getTextureRegion();
  }
}

Setters

The TinyVG class comes with a couple setters to adjust render options:

• setPosition() => Changes the origin (bottom left corner) of the sprite.
• setScale() => Changes the scale.
• setRotation() => Changes the rotation in degrees based on the origin point.
• setOrigin() => Changes the origin point for rotations.
• setCurvePoints() => The amount of points per path curve (Bezier, Arc) is used to calculate the curve.

Specification implementation status

https://tinyvg.tech/download/specification.pdf

Everything is implemented according to the specification.pdf except:

• [Partially] Draw Line Path (No variable line width, help wanted)
• [Partially] Outline Fill Path (No variable line width, help wanted)

Installation

0. Add ShapeDrawer as dependency (See their readme for instructions).

1. Open or create gradle.properties in the root folder of your project, add the following line:

gdxTinyVGVersion=VERSION

Check Jitpack for the latest version and replace VERSION with that.

2. Add the jitpack repo to your build file.

allprojects {
    repositories {
        // ...
        maven { url 'https://jitpack.io' }
    }
}

3. Add that to your core modules dependencies inside your root build.gradle

project(":core") {
    // ...

    dependencies {
        // ...
        implementation "com.github.lyze237:gdx-TinyVG:$gdxTinyVGVersion"
    }
}

Html/Gwt project

1. Gradle dependency:

implementation "com.github.lyze237:gdx-TinyVG:$gdxTinyVGVersion:sources"

2. In your application's .gwt.xml file add (Normally GdxDefinition.gwt.xml):

<inherits name="dev.lyze.tinyvg"/>

Help

• Paths require config.stencil enabled and set to at least 2 in your launcher configuration.
  • In lwjgl3 modules this is done via configuration.setBackBufferConfig(8, 8, 8, 8, 16, 2, 0); (The 2)
• Cropping the TVG file to the appropriate size requires a depth buffer.

How to test

By default, if you run ./gradlew test gradle runs headless tests. If you want to test lwjgl tests (so with an actual gui), then you need to run them with ./gradlew test -Plwjgl=true

Set environment variable SLEEPY to a millisecond number to sleep between each LWJGL test. (For example: SLEEPY=3000 would wait 3 seconds after every test.)
